Overview:
All Fast Fix products are made up of a polyurethane (PUR) or a polyisocyanurate (PIR) insulating core that is structurally and thermally superior to any other insulating material. PU or PIR panel cores are thermally bonded to the panel skins during the manufacturing process.
The Fast Fix Housing System is one of the only complete multi-storey systems available that achieves structural requirements and energy efficient ratings without needing additional trades and materials.
Reaching Lock-up Stage is one simple installation process that saves the owner and builder a considerable amount of time and money. It allows the builder to draw claims faster and the owner to move in sooner.
Products
External Wall Panel
Thickness: 90 mm
R-Value: 3.4
- Used for Ground Floor & First Floor External Walls
- Embedded Structural Steel
- High-Density Polyisocyanurate (PIR) Insulation
Internal Wall Panel
Thickness: 65 mm
R-Value: 2.5
- Internal Partition Wall
- Rigid, Easy to Install Wall Panel
- High-Density Polyisocyanurate (PIR) Insulation
Floor Panel
Thickness: 100/150 mm
R-Value: 4.9/7.7
- Capable of Large Spans
- Quick & Easy to Install
- Embedded Structural Steel
- High-Density Polyurethane (PUR) or Polyisocyanurate (PIR) Insulation
Roof Panel
Thickness: 75/100/150 mm
R-Value: 4.2/5.9/8.4
- Simple Skillion Roof
- Capable of Large Spans
- Pre-Painted Galvanised Iron (PPGI) External Skin, Able to be used as Finished Eaves & Ceiling
- High-Density Polyisocyanurate (PIR)
Benefits of FastFix
Builder Benefits
If you are a builder looking to move away from the problems that traditional brick and timber homes come with, to an innovative building solution that provides benefits to both the builder and home owner, then look no further than our FastFix Residential SIPs System.
- Fast and Simple Installation
- One Installation Team to Lock-up
- Less Reliance on Skilled Trades
- Less Wastage On-Site
- Reduced Supply Chain for Trades and Materials
- Pre-cast Conduits for Simple Electrical Wiring.
- Reduced Scaffolding and Equipment Hire Costs
Home Owner Benefits
Our FastFix Residential SIPs Panels provide the owner with a number of benefits, from having flexibilty in design, through to the superior comfort that the SIPs panels create, making the FastFix Residential SIPs System a perfect solution for your new home.
- Unique Design Opportunities
- Flexibility in Internal & External Finishes
- Extremely Energy Efficient
- High Thermal & Acoustic Properties
- Superior Interior Comfort
- Larger Internal Floor Area, when Compared to a Double Brick House of the same Design and Footprint
